Description
A medium duty flexible Food Grade PVC suction/discharge hose reinforced with a Rigid PVC spiral. It has a mirror smooth bore for ease of cleaning & to minimise friction losses. The materials used in the manufacture of this product meet the requirements of AS2070 & FDA plastic materials for food contact use, and have been tested to European std 2002/72/EC which in addition to the standards above also covers product testing for plastizer migration.- Applications: Suitable for the transfer of most food grade products where there is a requirement for the hose material to meet FDA requirements. It is light weight and extremely flexible. It is also an excellent medium duty general purpose suction and delivery hose.
- Colour: Clear with lt/blue rigid spiral
- Temperature Range: -5°C to +60°C
- Chemical Resistance: Good
- Flexibility: Excellent
- Abrasion Resistance: Good
| Nominal in mm’s | Working Pres. @ 20oC | |||||||
| Barfell Product Code | I.D | O.D | Vacuum Rating KPa/20oC | Mpa | P.S.I | Weight Kg/m | Min Bend Radius in mm | Coil Lengths in Metres |
| 206360 | 19.3 | 24.9 | -90.0 | 0.7 | 100 | 0.24 | 55 | 20,40 |
| 206361 | 25.2 | 31.0 | -90.0 | 0.7 | 100 | 0.37 | 75 | 20,40 |
| 206362 | 31.8 | 37.8 | -90.0 | 0.7 | 100 | 0.44 | 100 | 20,40 |
| 206363 | 38.4 | 45.2 | -90.0 | 0.6 | 85 | 0.56 | 140 | 20,40 |
| 206364 | 44.4 | 51.8 | -90.0 | 0.6 | 85 | 0.67 | 160 | 20,40 |
| 206365 | 50.8 | 58.8 | -90.0 | 0.5 | 70 | 0.85 | 200 | 20,40 |
| 206365 | 63.7 | 72.3 | -90.0 | 0.5 | 70 | 1.176 | 240 | 20 |
| 206367 | 76 | 85.6 | -90.0 | 0.4 | 55 | 1.42 | 350 | 20 |
| 206368 | 102.2 | 114.2 | -90.0 | 0.4 | 55 | 2.52 | 400 | 20 |
